SORT | TECHNICAL PARAMETERS | ||||
Signal output form | Digital output P G | Analog output V/MA/R G | |||
Output characteristics | TL liquid / square wave | Voltage(V):0-5v,0-10v,1-5v | |||
Parallel output,Serial,ssi Port, MHz, profibus, CanOpen | Current(MA):4-20mA,0-20mA | ||||
RS485 | Resistance(R):0-5kΩ,0-10KΩ,others | ||||
Supply Voltage | DC5V,DC5-24V | DC5V,DC10V, | |||
Measure stroke | 500mm | 400mm | |||
Maximum speed reciprocating | 600 | 600 | |||
Definition | 0.004,0.005,0.01 others | Nature of infinitesimal | |||
Measurement wire | Φ0.6 | Φ0.6 | |||
Linearity | 0.05%FS | 0.1%FS | |||
Pull material | Stainless steel | Stainless steel | |||
Work force | About 5N | About 5N | |||
Operating temperature | -25℃~+85℃ | -25℃~+85℃ | |||
Storage temperature | -35℃~+95℃ | -35℃~+95℃ | |||
Weight | 100g | 100g | |||
Useful life | >1×106 times | >1×106 times | |||
Protection grade | IP54 (Criterion) | IP54 (Criterion) | |||
MNH-20-P | Measurement range | resolution | Output characteristics | Supply voltage | Incremental type |
MNH-20-V/MA/R | Measurement range | Nature of infinitesimal | Output characteristics | Supply voltage | Mixed type |
MNH-20-G | Measurement range | Definition | Output characteristics | Supply voltage | Absolute value type |
SHENZHEN MINUO ELECTRONICS CO.LTD was founded in 2004,The company has the top bump type of conductive plastic potentialsensor resistance railresearchand development and manufacturing and thecoretechnology. It is the earlier high-tech enterprises engaged in the electrically conductive plastic potentiometer(Angle) of research and development and production in China.We have obtained several patents,MINUO product therefore won the good market reputation and industry brand awareness.
We with one-pointed,focus,focus,professional industry workman for the enterprise development concept.Continue to participate in future industrial 4.0 sensor core technology research and development,strive to build the world industrial automation engineer preferred displacement (perspective) sensor.Continuously improveproductqualityandservicequalitiosatistpesoaliztie
MINUO main production and sales of conductive plastic displacement sensor(electronic rule),Rotary displacementsensor,Draw wire position sensor,transmitter, magnetostrictive displacement sensor,Digital display intelligent meter,grating scale , Range from 0mm-30mm ,the precisionof products are 0.1% 0.05%,5um,1um,0.5um.The varieties, complete specifications and models, range range service life and accuracy in the leading position in the industry.
Products are widely used in aviation, military industry, machinery, engineering machinery, engineering,automation control system requires accurate measurement of displacement.
