KTW-A-25mm Precision Linear Transducers Designed For Mounting In Hydraulic Or Pn Push - pull potentiometer

KTW-A-25mm Precision Linear Transducers Designed For Mounting In Hydraulic Or Pn Push - pull potentiometer

Model NO.: KTW-A-25mm
Price:: USD 41.00-41.00 / piece
Delivery: FOB
Minimum order quantity: 1 piece
Supply Ability: 50000 piece / Month
Country of Origin: Shenzhen

Quantity:

Product Description
Basic Information

Place of Origin:CN;GUA
Type:Slide Potentiometer
Technology:Carbon Film
Brand Name:MINUO
Model Number:KTW-A-25mm
Resistance:5K/10K OHM
Resistance Tolerance:20%
Rated Power:0.5W
Max. Operating Voltage:24 V
Operating Temperature:55 ~+125

KTW Linear Position Sensor and Components

Standard Dimensions:

KTW-A

KTW Pull Pole series linear position sensors are designed for precise measurement of displacement and length. The Measuring range of KTW is up to 1500mm with repeatability of ±0.01mm and linearity of 0.05% (model size>350mm).Its structure is designed for simple installation and reliable work. Anodized aluminium housing can contribute to nice appearance and super corrosion resistance. By adopting conductive plastic track inside ,the product could run smoothly and have low-noise output signals.

There is a cardan joint or ball-bearing coupling at the top of pull pole to offset the effects of misalignment with the actuating part. Credited to the technology of trimming resistance, MINUO could not only provide you with required linearity, but also any resistance you need, such as 5678Ω or 8765Ω.

Output signal mode

A.Resistance: 1K,2K, 5K,10K,20K Ω

B.Current: 4-20mA

C.Power: 5V,10V,12V,24V

D.Related digital indicator: up-limit and bottom-limit setting function

(relay output, analogue, RS232/485 interface)

Product Characterist

1.Simple structure, small size, light weight, affordable, but with stable and high

precision quality.

2.Less impact generated by the environment (Such as temperature, humidity,

magnetic interfere etc).

3.Any function of input and output can be implemented.
