Resistance element | Conductive plastic | |
Standard resistance values(Ω) | 1K,5K,10K(Special max.100K) | |
Resistance accuracy | standard level(%) | ±20 |
Precision level(%) | ±10 | |
Linearity accuracy | standard level(%) | ±2 |
Precision level(%) | ±1 | |
Linearity type(IEC 60393) | Independent linearity | |
Maxing wiper current | 100μA | |
Maxing current pass wiper(3″time limit) | 1mA | |
Power rating(+70℃) | 0.5 Watt | |
End voltage:Supply voltage(%) | <0.5% | |
Electrical Travel | Standard type340°±5°(Other spec. optional) | |
Resolution | Infinite | |
TCR | ±400ppm/℃ | |
Insulation resistance | 1000MΩ(500V DC) | |
Dielectric strength | 500V AC | |
MECHANICAL CHARACTERISTICS |
Customized the special Special electrical/mechanical degree;With stop needle;With mounting tray. | |
Mechanical angle | 360° | |
Maxing rotaty speed | 250rpm | |
Starting torque | 1.4mN·m | |
Rotational torque | 1.0mN·m | |
Bearing type | Sleeve | |
Operating life | ||
Operating temperature | —50℃~+105℃ | |
MATERIALS | |
Hollow trun material | Plastic |
Housing | Plastic |
Terminals | Copper, gold plated |
SHENZHEN MINUO ELECTRONICS CO.LTD was founded in 2004,The company has the top bump type of conductive plastic potentialsensor resistance railresearchand development and manufacturing and thecoretechnology. It is the earlier high-tech enterprises engaged in the electrically conductive plastic potentiometer(Angle) of research and development and production in China.We have obtained several patents,MINUO product therefore won the good market reputation and industry brand awareness.
We with one-pointed,focus,focus,professional industry workman for the enterprise development concept.Continue to participate in future industrial 4.0 sensor core technology research and development,strive to build the world industrial automation engineer preferred displacement (perspective) sensor.Continuously improveproductqualityandservicequalitiosatistpesoaliztie
MINUO main production and sales of conductive plastic displacement sensor(electronic rule),Rotary displacementsensor,Draw wire position sensor,transmitter, magnetostrictive displacement sensor,Digital display intelligent meter,grating scale , Range from 0mm-30mm ,the precisionof products are 0.1% 0.05%,5um,1um,0.5um.The varieties, complete specifications and models, range range service life and accuracy in the leading position in the industry.
Products are widely used in aviation, military industry, machinery, engineering machinery, engineering,automation control system requires accurate measurement of displacement.
